EnerSys DataSafe 12HX50-FR 12V 54W UPS Battery - Compact VRLA
EnerSys DataSafe 12HX50-FR 12V 54W UPS Battery - Compact VRLA
Compact UPS power at exceptional value. As battery specialists since 2010, we deliver competitive pricing on the EnerSys DataSafe 12HX50-FR high-rate VRLA battery. This 12V 54W battery provides reliable 15-minute backup power for small to mid-size UPS systems. Featuring UL94 flame retardant construction, flexible terminal options, and 10-year design life, get guaranteed compatibility with IT and telecom equipment at unbeatable value.
UL Listed
MH16464
Ships Fast
In Stock
Battery Specialist
Since 2010
Compact Size
Space-saving
Quick Specifications
Replaces: HX50, 12HX50, 12HX50T-FR
Specifications: 12V, 12Ah @ 8hr rate, 54W @ 15min rate, Sealed Lead Acid VRLA
Dimensions: 6.0" × 3.9" × 3.9" (152mm × 99mm × 99mm)
Average Lifespan: 10-year design life in float service at 77°F
Compatibility: Small to mid-size UPS systems, network equipment, emergency lighting
Exceptional Value & Performance
Reliable backup power
Easy installation
Safety certified
Maintenance-free
Professional UPS Battery Features
- ✓ High-Rate Optimized: Computer-optimized electrochemistry for 54W @ 15-minute rate
- ✓ UL1778 Compliant: Flame retardant case and cover meet strict UL standards
- ✓ Flexible Terminals: Faston tabs or bolt terminals for easy installation
- ✓ AGM Technology: Absorbed Glass Mat separator for spill-proof operation
- ✓ Compact Design: Space-saving footprint perfect for crowded cabinets
What's Included:
- • EnerSys DataSafe 12HX50-FR VRLA Battery
- • Faston Tab Configuration
- • Professional Installation Guide
- • Safety Data Sheet
Clearly Specified Technical Details
| DataSafe 12HX50-FR Complete Specifications | |
|---|---|
| Model Number | 12HX50-FR (Also known as HX50, 12HX50) |
| Chemistry | Valve Regulated Lead Acid (VRLA), AGM |
| Nominal Voltage | 12 Volts |
| Capacity @ 8hr Rate | 12 Ah to 1.75 VPC @ 77°F (25°C) |
| Power @ 15min Rate | 54 Watts to 1.67 VPC @ 77°F (25°C) |
| Terminal Type | Faston Tabs |
| Length | 6.0 inches (152 mm) |
| Width | 3.9 inches (99 mm) |
| Height | 3.9 inches (99 mm) |
| Weight | 9.1 lbs (4.1 kg) |
| Internal Resistance | 12.2 mΩ |
| Short Circuit Current | 720 Amps |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Float Voltage | 2.25-2.28 VPC @ 77°F (25°C) |
| Design Life | 10 Years @ 77°F (25°C) |
| UL Listing | File No. MH16464 |
No Assembly
Ready to install
Multiple terminals
Spill-Proof
AGM sealed
Non-spillable certified
Maintenance-Free
VRLA technology
No water needed
Advanced VRLA Construction Features
Professional-Grade AGM Technology
- • Absorbed Glass Mat Separator: Complete electrolyte absorption for spill-proof operation
- • High-Performance Plates: Corrosion-resistant design for extended service life
- • Self-Resealing Vents: Flame-arresting design prevents oxygen ingress
- • Hermetically Sealed: Leak-resistant construction over product life
Safety & Compliance Features
- • UL94 Flame Retardant: Case and cover meet UL1778 requirements
- • Compact Footprint: Perfect for space-constrained installations
- • ISO Certified Manufacturing: ISO 9001:2008 and ISO 14001:2004
- • Non-Hazardous Shipping: IATA Special Provision A67 and 49 CFR approved
Value Comparison: DataSafe vs. Standard UPS Batteries
| Feature | DataSafe 12HX50-FR | Standard UPS Batteries |
|---|---|---|
| High-Rate Performance | 54W @ 15-minute rate | Limited high-rate capacity |
| Size/Weight | Compact 9.1 lbs | Bulkier designs |
| Safety Certification | UL1778 flame retardant | Basic safety features |
| Design Life | 10 years @ 77°F | 3-5 years typical |
| Terminal Options | Faston or bolt | Limited options |
| Initial Capacity | 100% from day one | May require conditioning |
Installation & Charging Requirements
The DataSafe 12HX50-FR is designed for easy installation in small to mid-size UPS systems. For optimal performance:
- • Float Voltage: Maintain 2.25-2.28 VPC at 77°F (25°C)
- • Temperature Range: -4°F to 122°F (-20°C to 50°C) operating
- • Storage: Can be stored up to 6 months at 77°F before freshening charge
- • High Current Recharge: Safely accepts high current rates for fast recovery
For compatible UPS chargers, explore our 12V charger selection.
Guaranteed Compatibility & Applications
Direct Replacement For:
- EnerSys HX50, 12HX50, 12HX50T-FR
- Small to mid-size UPS systems requiring 12V 54W @ 15-minute rate
- Network equipment backup power
- Emergency lighting systems
- Security and access control panels
Ideal Applications:
- Office UPS Systems: Desktop and workstation protection
- Network Equipment: Routers, switches, and modems
- Small Server Rooms: Entry-level rack mount UPS units
- Security Systems: Alarm panels and door access controls
- Medical Devices: Portable equipment backup power
Secure Checkout
SSL Encrypted • PCI Compliant
Frequently Asked Questions
Q: What battery replaces the EnerSys DataSafe 12HX50-FR?
A: The 12HX50-FR is also known as HX50, 12HX50, and 12HX50T-FR. It's a direct replacement for any of these model numbers in UPS applications requiring 12V 54W @ 15-minute rate performance.
Q: Which UPS systems use the DataSafe 12HX50-FR battery?
A: This compact battery is ideal for small to mid-size UPS systems, desktop UPS units, network equipment backup, and emergency lighting systems requiring 54W high-rate performance.
Q: How long does the DataSafe 12HX50-FR last in service?
A: The 12HX50-FR has a 10-year design life in float service at 77°F (25°C). Actual life varies based on temperature, discharge depth, and maintenance practices.
Q: What are the exact dimensions of the DataSafe 12HX50-FR?
A: The battery measures 6.0" L × 3.9" W × 3.9" H (152mm × 99mm × 99mm) and weighs 9.1 lbs (4.1 kg), making it perfect for space-constrained installations.
Why Choose Tech Battery Solutions
Battery Specialists Since 2010
With extensive experience in UPS battery solutions, we understand the importance of reliable backup power for critical systems. Our partnership with EnerSys ensures you receive genuine DataSafe products with full manufacturer specifications.
Expert Support & Fast Shipping
The DataSafe 12HX50-FR ships from our warehouse with tracking provided. Need help selecting the right UPS battery? Our specialists can guide you through compatibility and help optimize your telecom or IT power infrastructure.
Compact Power You Can Trust
The EnerSys DataSafe 12HX50-FR delivers reliable 54W high-rate performance in a compact, lightweight design. Featuring UL1778 flame retardant construction, flexible terminal options, and 10-year design life, it's the perfect choice for space-conscious UPS installations. As battery specialists since 2010, we guarantee compatibility and provide expert support for your power protection needs.
