CSB XTV 1250F2-WT Wind Turbine Battery for Extreme Temperature
CSB XTV 1250F2-WT Wind Turbine Battery for Extreme Temperature
CSB XTV1250F2FR-WT Battery - 12V 5Ah Wind Turbine AGM, F2
Warranty
The 5 Ah Position
- 5 Ah nominal - the price list figure, on the XTV convention of badging the block by its 20 hour capacity. No current CSB sheet publishes the 8 hour or discharge table figures for this model.
- F2 Faston tab, 0.250 inch - the same tab as the 7.2 and 12 Ah WT blocks, so the connectors in an existing pack carry over.
- -20°C to 50°C - CSB rates the XTV-WT series to operate over this window; the per-part storage limit is not published for this model.
- Flame retardant case as standard - the price list lists the FR case as the standard build on every WT part, where the standard XTV range carries it as a surcharged option.
- Not a gel battery - CSB's current XTV-WT literature describes AGM construction with pure lead. The "hybrid gel" phrase belongs to older XTV sheets.
Technical Specifications
| CSB XTV1250F2FR-WT Specifications | |
|---|---|
| Part Number | XTV1250F2FR-WT (also written XTV1250F2-WT, XTV 1250F2-WT, XTV1250-WT, XTV1250 WT and xtv1250f2-wt) |
| Series | XTV-WT, Extreme Temperature, wind turbine, 12 volt top terminal |
| Battery Type | AGM, valve regulated lead acid (VRLA), pure lead construction (CSB XTV-WT series literature) |
| Nominal Voltage | 12V |
| Nominal Capacity | 5 Ah at the 20 hour rate (CSB price list); no per-part datasheet is currently published |
| Capacity, 8 Hour Rate | Not published in a current CSB document for this model |
| Watts Per Battery, 15 Minutes | Not published; this model is not on the XTV-WT extended tables (RA240531) |
| Maximum Charge and Discharge Current | Not published in a current CSB document; confirmed with your quote |
| Terminal Type | F2 Faston tab, 0.250 inch (CSB price list) |
| Dimensions | BCI group M6 case (CSB price list); length, width and height confirmed with your quote |
| Weight | Not published per unit; CSB ships 10 to a master carton at 47 lbs gross |
| BCI Group Size | M6 (CSB price list) |
| Float Charging Voltage | 13.5 to 13.8 VDC per battery at 25°C, the window CSB publishes across the XTV-WT range |
| Equalization Charging Voltage | 14.4 to 15.0 VDC per battery at 25°C, per the XTV-WT range sheets |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F), the XTV-WT series rating; per-part storage limit not published |
| Container Material | ABS, flame retardant, standard on the WT build (CSB price list) |
| Design Life | Up to 12 years in standby service, CSB's figure for the XTV-WT series; no per-part figure published |
| Warranty | 3 years (CSB, XTV-WT) |
| Country of Origin | Vietnam |
| Stock Status at CSB | Build-to-order (CSB price list), packed 10 to a master carton |
Where This Battery Is Used
- Small pitch system and hub control packs - strings specified around a 5 Ah, 12 volt block by the pitch drive manufacturer.
- Turbine controller and communications backup - low draw equipment in the nacelle that has to ride through the same event and the same vibration as the pitch pack.
- Like-for-like replacement - where the drawing calls for a 5 Ah F2 block and the pack is in a rotating assembly; on the ground, the standard XTV1255F2 carries 5.5 Ah in the same case group with a published datasheet.
Ordering and Freight
Frequently Asked Questions
Why are the dimensions and currents missing from this page?
Because CSB has not published a current datasheet for this model. The 2026 price list lists it, with capacity, terminal, case group, warranty and packing, and the XTV-WT series literature covers the chemistry and the temperature window, but the per-part sheets CSB publishes today cover the 7.2, 12 and 20 Ah WT blocks only. Older figures for the 5 Ah block are not repeated here. The quote from CSB carries the figures for the part they will build; keep that sheet with the pack.
Is the standard XTV1255F2 a substitute?
For a stationary installation, often yes: it is a 5.5 Ah, 12 volt block in the same M6 case group on the same F2 tab, rated to the same -20°C to 50°C discharge window, with a current CSB datasheet behind it and the same 3 year term. What it does not carry is the WT build. If the pack is in a rotating hub, specify the WT part and accept the lead time. If it is on the ground, the standard part is the better documented choice.
Is this an AGM battery?
Yes. CSB describes the XTV-WT range as VRLA pure lead AGM construction, and the range charges on the 13.5 to 13.8 volt float window. The phrase "hybrid gel" comes from older XTV literature and is not on any current CSB WT document. Set the charger for AGM.
How long is the lead time?
It is quoted per order, because the part is built when ordered rather than pulled from CSB's stock. The two stock items in the WT range are the 7.2 and 12 Ah blocks. If a pitch pack is down and the drawing allows either the 7.2 Ah WT block or the standard 5.5 Ah block, one of those may be the faster path, and a specialist will say so on the quote rather than leave a turbine waiting on a build slot.
Send the count per hub, the pitch drive model and the date the pack has to be back in service. A specialist confirms the build lead time with CSB, forwards the current figures for the part, and quotes the set in writing.
