Samlex PST-600-48 600 Watt Pure Sine Wave Inverter, 48V, Dual GFCI Outlets

$435.00
$348.00
(You save $87.00 )
SKU: PST-600-48
Availability: Usually ships in 24 hours
Shipping: Free shipping on orders $75 and up
Input Voltage: 48 VDC
Output: 120 VAC Pure Sine Wave
Continuous Power: 600 W
Surge Power: 1000 W
AC Outlets: NEMA 5-20R GFCI Duplex
Remote Control: RC-15A Optional (Sold Separately)
Samlex PST-600-48 600 Watt Pure Sine Wave Inverter, 48V, Dual GFCI Outlets

Samlex PST-600-48 600 Watt Pure Sine Wave Inverter, 48V, Dual GFCI Outlets

$435.00
$348.00
(You save $87.00 )
Adding to cart… The item has been added
Description

Samlex PST-600-48 - 600 Watt 48V Pure Sine Wave Inverter, Dual GFCI Outlets

Not every 48 volt system needs kilowatts of AC; most just need an outlet that works. The Samlex PST-600-48 is a 600 watt 48V inverter that gives a solar cabin, telecom room or electric machine a pair of GFCI-protected household outlets fed straight from the bank. Peak efficiency runs past 90 percent, the maximum draw is 20 amps, and idle consumption of under 300 milliamps means it can simply stay on.

Warranty

Warranty. Samlex America warrants the PST-600-48 for 3 years. Full terms are confirmed in writing with your quote.

The Everyday Outlet for 48V Systems

20 amp maximum draw
Light cabling, a single 20 amp fuse, and a hookup that takes minutes rather than an afternoon.
Best-in-family efficiency
Above 90 percent peak, the highest of the three PST-600 voltages, with under 300 milliamps of idle draw.
Protected duplex
Ground-fault shutdown guards both outlets at the household 5 to 6 milliamp threshold.
  • Pure sine wave output, under 3% THD, up to 5.1 amps at 120 VAC.
  • 1000 watt surge rating for switch-on spikes.
  • UPC protections: low voltage shutdown at 40 V, high voltage limit, overload, short circuit, over-temperature.
  • RC-15A remote optional; wired on/off inputs on the terminal block; FCC Part 15(B) Class B.

Technical Specifications

Samlex PST-600-48 Specifications
Part NumberPST-600-48 (also searched as PST 600 48, PST600-48, PST 600)
Output WaveformPure sine wave, under 3% THD
Continuous Power600 W
Surge Power1000 W
Maximum Output Current5.1 A
AC Output120 VAC ±3%, 60 Hz ±1%; NEMA 5-20R GFCI duplex receptacle
DC Input Voltage48 VDC nominal, 42 - 60 VDC operating range per current spec sheet
DC Input Current20 A maximum; under 300 mA at no load
DC ConnectionsTubular screw-down terminals; internal 20 A fuse (58 V rated)
Peak EfficiencyOver 90%
ProtectionsLow voltage alarm 42 V, shutdown 40 V (auto reset 46 V); high voltage shutdown 64 V; overload, short circuit, over-temperature (auto reset); ground fault on GFCI outlets; reverse polarity (fuse)
Remote Control2-wire and 1-wire on/off inputs; RC-15A LED remote sold separately (16.5 ft cable)
CoolingTemperature-controlled fan
Operating Temperature-4°F to 104°F (-20°C to 40°C)
Dimensions9.37 x 10.87 x 3.23 inches (238 x 276.2 x 82 mm)
Weight5.9 lbs (2.7 kg)
StandardsETL listed to UL 458 and CSA C22.2 No. 107.1 per current spec sheet; FCC Part 15(B) Class B; RoHS
Warranty3 years (Samlex America)
Technical Documentation
PST-600-48 Product Manual (PDF) · PST-600-48 Specification Sheet (PDF)

Where This Inverter Is Used

  • 48V solar cabins and tiny systems - the outlet for lights, laptops and small appliances.
  • Telecom and battery rooms - corded test gear on plant power.
  • Electric machines and carts - device charging from traction voltage.
  • 48V backup banks - essentials through an outage without a big inverter idling.

Ordering

Kit optional, sizing first. At a 20 amp draw, the DC-1000-KIT 100A kit is generous but convenient. Bigger 48V plans belong on the PST-1500-48. Send counts and ZIPs for a written quote in 24 to 48 hours.

Frequently Asked Questions

Who runs 600 watts at 48 volts?

Solar cabins, telecom rooms and electric equipment that standardized on 48V and still need a corded outlet now and then. This inverter serves that outlet from the existing bank at a 20 amp maximum draw, no voltage converter in between.

PST-600-48 or PST-1500-48?

Load size decides. Chargers, laptops and monitoring gear live happily under 600 watts; a microwave, corded tool or anything else with real appetite calls for the 1500. Both share the 48V input design and 3 year term.

Where does the remote connect?

The optional RC-15A LED remote plugs in on a 16.5 foot cable, and the wired on/off inputs on the terminal block take a switch or ignition signal, so the inverter can live beside the batteries unseen.

How much surge does it really have?

1000 watts for startup, about 166 percent of the continuous rating. That absorbs power-brick inrush and small pump starts, but compressors and heaters are outside this inverter's job description.

One good outlet for the whole 48V system.

Order online, or send your load list and delivery ZIP and a battery specialist will confirm fit and pricing in writing, with no obligation to buy.
