Leoch PLH190FT-A Pure Lead Long Life Battery
Leoch PLH190FT-A Battery - 12V 190Ah Pure Lead Front Terminal
Warranty
What Pure Lead Buys You on Float
- Wide thermal window - operates from -40°C to +65°C, which covers an unconditioned hut through both seasons.
- Two-year shelf life - Leoch's warranty form calls for a freshening charge every 5 to 6 months while a spare is in storage, before final installation, in a dry area no warmer than 77°F.
- Sealed terminals, minimal ventilation - step terminal sealing at the posts; Leoch lists minimal ventilation requirements, with remote venting where a site requires it.
- Certified with ISO 9001, ISO 14001, IATF 16949 and UL - the paperwork a carrier-grade site audit expects.
Technical Specifications
| Leoch PLH190FT-A Specifications | |
|---|---|
| Part Number | PLH190FT-A (Leoch catalog form PLH190FT(A); also searched as plh190ft, leoch plh190ft-a) |
| Battery Type | Pure lead AGM, valve regulated (VRLA), front terminal |
| Nominal Voltage | 12V |
| Nominal Capacity | 190 Ah at the 10-hour rate to 1.80 VPC |
| Terminal Type | Front terminal, M6 (Leoch T8) |
| Length | 22.0 inches (559 mm) |
| Width | 4.92 inches (125 mm) |
| Height | 12.6 inches (320 mm) |
| Weight | 127.0 lbs (57.6 kg) |
| Operating Temperature | -40°C to +65°C (-40°F to +149°F) |
| Shelf Life | Up to 2 years; self-discharge at or below 2% per month at 77°F; freshening charge every 5 to 6 months in storage (warranty form) |
| Design Life | 20 years at 77°F (Leoch) |
| Warranty | 60 months full replacement (Leoch) |
Where This Battery Is Used
- Central offices and carrier cell sites - the -48V plant string.
- Remote and unconditioned cabinets - sites that swing hot and cold through the year and get visited on a schedule, not on demand.
- Rail and wayside signaling - long service intervals in enclosures nobody wants to open in January.
- Utility substations - switchgear tripping and SCADA backup where the replacement cycle is measured in decades.
Ordering and Freight
Frequently Asked Questions
What is the difference between PLH190FT and PLH190FT-A?
Leoch's current catalog lists them together as PLH190FT(A), with one set of figures: 190 Ah at the 10-hour rate to 1.80 VPC, 22.0 by 4.92 by 12.6 inches, and an M6 (T8) terminal. If your submittal or an old purchase order says PLH190FT with no suffix, send it over and we will confirm the match in writing before you order.
Why choose pure lead over a standard AGM at the same capacity?
Service life on float. Leoch rates the PLH at a 20-year design life at 77°F, against 12 years for its LPF front-terminal AGM. A longer design life means fewer battery changes per site, which counts when every visit involves a truck roll and 127-lb lifts.
How does a 20-year design life square with a 60-month warranty?
Design life is Leoch's engineering estimate of service under ideal float conditions. The warranty is the period in which Leoch will replace a failed unit. Terms are confirmed in writing with your quote.
Does it run in a hot, unconditioned cabinet?
The operating window runs to +65°C. Sustained high ambient still shortens any VRLA's service life, so tell us the cabinet conditions with your quote request and a specialist will tell you what to expect at your site.
Can I replace a discontinued 190 Ah front-terminal unit with this?
Usually, but confirm three things first: voltage, footprint and terminal hardware. The footprint is 22.0 by 4.92 inches, and the M6 front terminal is the detail most often missed. Send a label photo of the outgoing unit and the tray dimensions and we will check the drawing against your rack.
Send the quantity, your delivery ZIP and your requested-by date. A specialist confirms availability, the warranty term, volume pricing and freight in writing, with no obligation to buy.
