Leoch LPX12-9 12V high rate AGM UPS battery with T2 terminals
Leoch LPX12-9 12V high rate AGM UPS battery with T2 terminals

  • Free Shipping

    Orders $75 & Up

  • 30-day Money Back

    Guarantee*

  • 100% Secure Online Shopping

    SSL - Verified Merchant

Leoch LPX12-9 High Rate AGM Battery

$24.50
SKU: LPX12-9
Availability: Shipping Lead Time is 1 to 2 Days
Shipping: Free shipping on orders $75 and up
Voltage: 12V
Capacity: 7.98 Ah (10-hour rate to 1.80 VPC at 25C); 8.8 Ah at C/20
Chemistry: High-rate AGM VRLA
Terminal: T2 tab (T1 option shown on per-part sheet)
Dimensions: 5.90 x 2.60 x 3.90 in (L x W x total H)
Design Life: 5 years at 25C (Leoch)
Leoch LPX12-9 High Rate AGM Battery

Leoch LPX12-9 High Rate AGM Battery

$24.50

Out of stock

Description

Leoch LPX12-9 Battery - 12V High Rate AGM UPS Battery

The Leoch LPX12-9 is the higher-output LPX block in the familiar 5.9 by 2.6 inch case. Leoch lists 33.3 watts per cell at 15 minutes to 1.67 VPC, 7.98 Ah at the 10-hour rate and 8.8 Ah at the 20-hour rate on the current model sheet. That rate labeling matters when an existing UPS battery is being compared by the number printed on its case.

Warranty

Leoch warrants LPX batteries below 30 Ah for 24 months in UPS applications. Publication LB-LPX12-9.0-PD-EN-V1.0-20240116 gives a five-year design life at 25°C; the design-life estimate and warranty period are different figures. Terms are confirmed in writing with your quote.

More High-Rate Output in the 9Ah Class

33.3 WPC at 15 minutes
The published rating supports short UPS runtime calculations at the cutoff voltage used for high-rate comparisons.
Rate-labeled capacity
The 7.98 Ah C/10 and 8.8 Ah C/20 figures keep a slower-rate capacity from being mistaken for a high-rate promise.
T2 tab connection
The current model uses the wider tab common in higher-output compact UPS blocks.
  • 7.98 Ah at the 10-hour rate and 8.8 Ah at the 20-hour rate on the current sources.
  • 33.3 WPC at 15 minutes to 1.67 VPC at 25°C.
  • Five-year design life at 25°C, separate from the 24-month warranty.

Technical Specifications

Leoch LPX12-9 Specifications
Part NumberLPX12-9; Leoch publication uses LPX12-9.0 (also written LPX12 9 and LPX129)
Battery TypeHigh-rate AGM, valve regulated lead acid (VRLA)
Nominal Voltage12V
Nominal Capacity7.98 Ah at the 10-hour rate to 1.80 VPC; 8.8 Ah at the 20-hour rate to 1.75 VPC
High-Rate Output33.3 WPC at 15 minutes to 1.67 VPC
Short-Circuit Current246.4 A
Internal ResistanceApproximately 15 milliohms at 25°C, fully charged
Terminal TypeT2 tab; T1 option identified on the per-part sheet
Length5.90 in (149.86 mm)
Width2.60 in (66.04 mm)
Container Height3.68 in (93.47 mm)
Total Height3.90 in (99.06 mm)
Weight5.87 lbs (2.7 kg)
Design Life5 years at 25°C, per Leoch publication LB-LPX12-9.0-PD-EN-V1.0-20240116
Warranty24 months from Leoch for LPX batteries below 30 Ah in UPS applications
Technical Documentation
Leoch LPX12-9.0 datasheet, publication LB-LPX12-9.0-PD-EN-V1.0-20240116 (PDF)

Where This Battery Is Used

  • Compact UPS enclosures that call for a T2 terminal battery.
  • Network and banking equipment backup power.
  • Emergency-lighting and control cabinets with short reserve windows.
  • High-power DC backup supplies using the LPX12-9 footprint.
Minimum order is 4 units. Send the quantity, UPS model, existing battery label and delivery ZIP. The written quote confirms the capacity basis, terminal and current availability in 24 to 48 hours.

Frequently Asked Questions

What is the Leoch warranty on the LPX12-9?

The current Leoch LPX warranty provides 24 months for batteries below 30 Ah in UPS applications. The quote confirms the applicable term.

Is the LPX12-9 a 9Ah battery?

The model name uses 9, while the measured capacity depends on rate. Current Leoch sources give 7.98 Ah at C/10 and 8.8 Ah at C/20.

Does it use T1 or T2 terminals?

Leoch Americas lists T2 for the current model. The individual sheet also identifies a T1 option, so the installed connector should be photographed and confirmed.

How is the LPX12-9 different from the LPX12-7?

Both use a similar compact case, but the LPX12-9 increases the 15-minute rating from 29 to 33.3 watts per cell and carries more reserve capacity.

Need the lower-output LPX block?The LPX12-7 keeps the same application class with 29 WPC at 15 minutes and a 7.23 Ah C/10 rating.
Confirm the LPX12-9 rating before the swap

Send the UPS model, battery label, terminal photo, quantity and delivery ZIP. A specialist checks the capacity basis and connector before quoting the order.
