Leoch LPX12-7 High Rate AGM Battery
$23.95
SKU:
LPX12-7
Availability:
Shipping Lead Time is 1 to 2 Days
Minimum Purchase:
5 units
Shipping:
Free shipping on orders $75 and up
Voltage:
12V
Capacity:
7.23 Ah (10-hour rate to 1.80 VPC at 25C)
Chemistry:
High-rate AGM VRLA
Terminal:
T2 tab (T1 option shown on per-part sheet)
Dimensions:
5.94 x 2.56 x 3.92 in (L x W x total H)
Design Life:
5 years at 25C (Leoch)
Leoch LPX12-7 High Rate AGM Battery
$23.95
Leoch LPX12-7 Battery - 12V 7.23Ah High Rate AGM
The Leoch LPX12-7 is a high-rate AGM block for small UPS systems that need more short-duration output than a general-purpose 7Ah battery. Leoch publishes 29 watts per cell at 15 minutes to 1.67 VPC and 7.23 Ah at the 10-hour rate. The 5.94 by 2.56 inch case is common, but the T2 terminal and total height still need to match the installed harness and tray.
Warranty
Leoch warrants LPX batteries below 30 Ah for 24 months in UPS applications. Publication LB-LPX12-7.0-PD-EN-V2.0-20240123 gives a five-year design life at 25°C; design life is not the warranty period. Terms are confirmed in writing with your quote.
Sized for the UPS Discharge Window
29 WPC at 15 minutes
The model is rated for the short, high-current window that carries a UPS load through transfer or shutdown.
Two capacity reference points
Leoch lists 7.23 Ah at C/10 and 8.0 Ah at C/20, so comparisons should use the same discharge rate.
T2 terminal
The wider tab handles the published high-rate duty, but it must match the equipment connector already in the enclosure.
- 7.23 Ah at the 10-hour rate to 1.80 VPC at 25°C.
- 105 A maximum discharge current for five seconds.
- Five-year design life at 25°C in the current per-part sheet.
Technical Specifications
| Leoch LPX12-7 Specifications | |
|---|---|
| Part Number | LPX12-7; Leoch publication uses LPX12-7.0 (also written LPX12 7 and LPX127) |
| Battery Type | High-rate AGM, valve regulated lead acid (VRLA) |
| Nominal Voltage | 12V |
| Nominal Capacity | 7.23 Ah at the 10-hour rate to 1.80 VPC; 8.0 Ah at the 20-hour rate to 1.75 VPC |
| High-Rate Output | 29 WPC at 15 minutes to 1.67 VPC |
| Maximum Discharge Current | 105 A for five seconds |
| Internal Resistance | Approximately 20 milliohms at 25°C, fully charged |
| Terminal Type | T2 tab; the per-part sheet also identifies a T1 option |
| Length | 5.94 in (151 mm) |
| Width | 2.56 in (65 mm) |
| Container Height | 3.68 in (93.5 mm) |
| Total Height | 3.92 in (99.5 mm) |
| Weight | 5.51 lbs (2.50 kg) |
| Design Life | 5 years at 25°C, per Leoch publication LB-LPX12-7.0-PD-EN-V2.0-20240123 |
| Warranty | 24 months from Leoch for LPX batteries below 30 Ah in UPS applications |
Where This Battery Is Used
- Small UPS battery trays and replacement cartridges.
- Emergency-lighting systems with a short high-rate load.
- Banking and network equipment backup power.
- DC reserve systems built around T2 tab connections.
Minimum order is 4 units. Send the UPS model, quantity, delivery ZIP and a clear photo of the installed terminal. A specialist checks the fit and returns the written quote in 24 to 48 hours.
Frequently Asked Questions
What is the Leoch warranty on the LPX12-7?
The current Leoch LPX warranty provides 24 months for models below 30 Ah in UPS applications. Terms are confirmed with the quote.
Why are 7.23 Ah and 8.0 Ah both shown?
Capacity changes with discharge rate. Leoch lists 7.23 Ah at C/10 and 8.0 Ah at C/20; comparing two batteries requires the same rate and cutoff voltage.
Is this the same as any 12V 7Ah battery?
No. The footprint is common, but high-rate output, terminal width, total height and the UPS connector still control fit. Match all four before ordering.
Can I mix it with another brand in the same UPS bank?
A mixed bank can age and discharge unevenly. Send the full installed part number and string count so the replacement plan can be confirmed before the quote.
Match the LPX12-7 to the connector and tray
Send a label photo, connector photo, quantity and delivery ZIP. A specialist confirms the rate, terminal and footprint in writing.
