CSB XPL3500 12V 558W/Cell 5-Min Pure Lead AGM UPS Battery
CSB XPL3500 12V 558W/Cell 5-Min Pure Lead AGM UPS Battery
CSB XPL3500 Battery - 12V 85 Ah Extreme Power Long Life AGM
Warranty
Where the Case Changes
- A 10.28 by 6.63 inch case, 8.41 inches tall - measure the shelf before ordering, because this is the first size in the range that will not drop into a 2200 or 2700 position.
- 750 amps over 5 seconds - the peak discharge CSB publishes, which is inrush headroom rather than a sustained figure.
- 29.20 amps maximum charge current - the recovery ceiling, and the specification to check a shared rectifier against when the string grows.
- Rated -15°C to 50°C on discharge - 5°F to 122°F, with charge and storage held between -15°C and 40°C against a 25°C nominal.
- Storable to six months at 25°C - self discharge stays under 10 percent across 90 days, and a warmer stockroom brings the recharge date forward.
Technical Specifications
| CSB XPL3500 Specifications | |
|---|---|
| Part Number | XPL3500 (also searched as XPL 3500, XPL3500FR and xpl3500; CSB prints the flame retardant build as XPL 3500FR) |
| Series | XPL, Extreme Power long life, top terminal |
| Battery Type | AGM, valve regulated lead acid (VRLA), pure lead construction |
| Nominal Voltage | 12V |
| Nominal Capacity | 85 Ah at the 20-hour rate to 1.75 VPC at 25°C (77°F), per the CSB price list; the per-part datasheet rates this series in watts only |
| Watts Per Cell, 15 Minutes | 318 W to 1.67 VPC at 25°C |
| Watts Per Cell, 5 Minutes | 558 W to 1.67 VPC at 25°C |
| Watts Per Cell, 30 Seconds | not published by CSB for this model |
| Maximum Charge Current | 29.20 A |
| Maximum Discharge Current | 750 A (5 second rate) |
| Short Circuit Current | 2,206 A |
| Internal Resistance | Approximately 3.83 milliohms |
| Terminal Type | I2 threaded lead alloy insert, accepts an M6 bolt |
| Terminal Torque | 44.9 ±9.0 lbf-in (51.7 ±10.3 kgf-cm, 5.10 ±1.0 N-m) |
| Length | 10.28 inches (261.0 mm) |
| Width | 6.63 inches (168.5 mm) |
| Height | 8.41 inches (213.5 mm) |
| Weight | 56.86 lbs (25.80 kg) |
| Float Charging Voltage | 13.5 to 13.8 VDC per battery at 25°C (77°F) |
| Equalization Charging Voltage | 14.4 to 15.0 VDC per battery at 25°C (77°F) |
| Operating Temperature | Nominal 25°C (77°F); discharge -15°C to 50°C (5°F to 122°F); charge and storage -15°C to 40°C (5°F to 104°F) |
| Self Discharge | Less than 10 percent after 90 days at 25°C; storable to six months before a full recharge |
| Container Material | Polypropylene (UL 94-HB); flame retardant 94-V0 available on request |
| Standards | IEC 60896-21/22:2004; UL1973 Listed (MH66728); UL1989 Recognized (MH14533); TUV NORD to ISO 9001:2015 |
| Design Life | Up to 10 years in standby service at 25°C; greater than 12 years on the Eurobat 20°C basis |
| Warranty | 5 years (CSB, XPL Extreme Power range) |
| Country of Origin | Taiwan |
Where This Battery Is Used
- Mid-size UPS plant - cabinet strings backing a server room or a production cell through the transfer to generator.
- Switchgear control power - breaker tripping and closing duty, held charged for years and replaced on interval rather than on failure.
- Process and utility standby - installs where an unplanned stop costs more than the string, and the ten year design life is the reason for the size.
Ordering and Freight
Frequently Asked Questions
Why is there no 30 second rating for this model?
CSB prints a dash in that column on the XPL3500 datasheet where every other model in the range carries a figure. We publish what the manufacturer publishes, so this page states the 5 minute and 15 minute rates and stops there. If your application turns on a sub-minute discharge, the 4200 one size up carries a published 980 watts per cell at 30 seconds and is the safer specification.
Will an XPL3500 fit where a 2700 was?
Not usually. The 3500 is 10.28 inches long and 6.63 inches wide against the 2700's 8.98 by 5.45, so it needs about 1.3 inches more in both directions and 16 pounds more shelf rating. Height is close, 8.41 against 8.12. Send the internal shelf dimension and we will confirm in writing before anything ships.
The 3500 and 4200 both show 85 Ah. Is that right?
It is. Both blocks are built in the same case on the same capacity, and what separates them is plate configuration: the 4200 delivers 370 watts per cell at 15 minutes against 318, for 5.31 pounds more. This is the clearest illustration in the range that amp hours do not size a UPS string. Two batteries with identical capacity differ by 16 percent in the figure that decides your runtime.
What float voltage does it need?
13.5 to 13.8 VDC per battery at 25°C, with equalization at 14.4 to 15.0 VDC per battery. Keep charge current at or under 29.20 amps. If the room runs warmer than 25°C the float window should come down, and a specialist will tell you by how much for your ambient before you order.
Send the shelf dimensions you have and the load you need to carry. A specialist confirms the 3500 fits and covers it, or names what does, in writing with no obligation.
