CSB XPL2200 12V 366W/Cell 5-Min Pure Lead AGM UPS Battery

$216.95
SKU: XPL2200
Availability: Request Quote For Availability
Minimum Purchase: 4 units
Shipping: Free shipping on orders $75 and up
Voltage: 12
Capacity: 52 Ah (20-hour rate to 1.75 VPC at 25C); 201 W per cell (15-min to 1.67 VPC)
Chemistry: AGM VRLA, pure lead construction
Terminal: Top terminal, I2 insert, M6 bolt, 44.9 in-lbs
Features: EXTREME POWER
Dimensions: 8.98 x 5.45 x 8.12 in
CSB XPL2200 12V 366W/Cell 5-Min Pure Lead AGM UPS Battery

CSB XPL2200 12V 366W/Cell 5-Min Pure Lead AGM UPS Battery

$216.95
Adding to cart… The item has been added
Description

CSB XPL2200 Battery - 12V 52 Ah Extreme Power Long Life AGM

The XPL2200 is the entry point to CSB's Extreme Power range, a 12 volt 52 Ah block rated 201 watts per cell at the 15 minute rate to 1.67 volts per cell at 25°C. It shares its 8.98 by 5.45 inch case with the HRL12200W, so it drops onto the same shelf, and what the swap buys is pure lead plate construction and a longer manufacturer term. The 2200 in the name is a nominal figure for the whole block at the 5 minute rate: six cells at 366 watts each come to 2,196 watts, so the badge is close but the per-cell number is what a sizing sheet takes. The block runs 36.70 lbs with 5.60 milliohms of internal resistance and a 500 amp discharge ceiling.

Warranty

Warranty. CSB's term on the XPL range is 5 years. Design life is measured separately: up to 10 years in standby service at 25°C (77°F), and greater than 12 years on the Eurobat 20°C basis. Country of origin is Taiwan. Terms are confirmed in writing with your quote.

What Pure Lead Buys in the Same Case

201 watts per cell at 15 minutes
To 1.67 volts per cell at 25°C, with 366 watts at 5 minutes and 563 watts at the 30 second rate for the initial inverter step.
A five year term, not four
CSB warrants the Extreme Power range a year longer than the HRL line that shares this footprint, against the same 10 year design life.
500 amps of discharge ceiling
Enough headroom that a single string covers the step most 6 to 10 kVA cabinets present, without pairing banks.
  • 52 Ah at the 20 hour rate - to 1.75 volts per cell at 25°C. CSB rates the XPL line in watts on the per-part datasheet, so the amp hour figure comes from the CSB price list and is quoted here with its rate.
  • Float 13.5 to 13.8 VDC per battery - at 25°C (77°F), with equalization at 14.4 to 15.0 VDC per battery at the same temperature.
  • 18.30 amps maximum charge current - the ceiling for recovery after a discharge, and the number to check a fixed rectifier against before ordering.
  • I2 threaded insert taking an M6 bolt - torque to 44.9 plus or minus 9.0 lbf-in (5.10 plus or minus 1.0 N-m), identical across the range so lugs carry across.
  • UL1973 Listed and UL1989 Recognized - file numbers MH66728 and MH14533, built to IEC 60896-21/22:2004, with TUV NORD certification to ISO 9001:2015.

Technical Specifications

CSB XPL2200 Specifications
Part NumberXPL2200 (also searched as XPL 2200, XPL2200FR and xpl2200; CSB prints the flame retardant build as XPL 2200FR)
SeriesXPL, Extreme Power long life, top terminal
Battery TypeAGM, valve regulated lead acid (VRLA), pure lead construction
Nominal Voltage12V
Nominal Capacity52 Ah at the 20-hour rate to 1.75 VPC at 25°C (77°F), per the CSB price list; the per-part datasheet rates this series in watts only
Watts Per Cell, 15 Minutes201 W to 1.67 VPC at 25°C
Watts Per Cell, 5 Minutes366 W to 1.67 VPC at 25°C
Watts Per Cell, 30 Seconds563 W to 1.67 VPC at 25°C
Maximum Charge Current18.30 A
Maximum Discharge Current500 A
Short Circuit Current1,344 A
Internal ResistanceApproximately 5.60 milliohms
Terminal TypeI2 threaded lead alloy insert, accepts an M6 bolt
Terminal Torque44.9 ±9.0 lbf-in (51.7 ±10.3 kgf-cm, 5.10 ±1.0 N-m)
Length8.98 inches (228.0 mm)
Width5.45 inches (138.4 mm)
Height8.12 inches (206.3 mm)
Weight36.70 lbs (16.65 kg)
Float Charging Voltage13.5 to 13.8 VDC per battery at 25°C (77°F)
Equalization Charging Voltage14.4 to 15.0 VDC per battery at 25°C (77°F)
Operating TemperatureNominal 25°C (77°F); discharge -15°C to 50°C (5°F to 122°F); charge and storage -15°C to 40°C (5°F to 104°F)
Self DischargeLess than 10 percent after 90 days at 25°C; storable to six months before a full recharge
Container MaterialPolypropylene (UL 94-HB); flame retardant 94-V0 available on request
StandardsIEC 60896-21/22:2004; UL1973 Listed (MH66728); UL1989 Recognized (MH14533); TUV NORD to ISO 9001:2015
Design LifeUp to 10 years in standby service at 25°C; greater than 12 years on the Eurobat 20°C basis
Warranty5 years (CSB, XPL Extreme Power range)
Country of OriginTaiwan
Technical Documentation
CSB XPL2200 datasheet, 2026 (PDF)

Where This Battery Is Used

  • Small to mid UPS cabinets - the 6 to 10 kVA range where a four to eight block string carries the load through a transfer.
  • Telecom equipment rooms - 48 volt strings on float, sized from the 15 minute column rather than the capacity figure.
  • Upgrades from a standard high rate string - where the cabinet is staying and the requirement is a longer service life in the same space.

Ordering and Freight

At 36.70 lbs a block, a four unit string is about 147 lbs and ships freight pre-paid by LTL to a commercial address. A residential or limited-access delivery adds $100, the liftgate and access charge the carrier bills us. Give us the count, the delivery ZIP and the date you need it on site, and a specialist returns volume pricing and freight in writing inside 24 to 48 hours.

Frequently Asked Questions

Is the XPL2200 a 2200 watt battery?

Near enough to be useful, and not exact. CSB publishes 366 watts per cell at the 5 minute rate, and six cells come to 2,196 watts for the block, which is where the 2200 comes from. At the 15 minute rate the figure is 201 watts per cell, or about 1,206 watts for the block. Size from the per-cell number at the rate your cabinet requires, because the badge is a 5 minute nominal and most UPS sizing runs on 15.

What does the XPL2200 give me over an HRL12200W?

Same case, same shelf, same terminal hardware. The XPL is built on pure lead plates, carries a 5 year CSB term against the HRL's 4, and delivers 201 watts per cell at 15 minutes against 218. So it is a slightly lower power rating for a longer warranty and a different plate construction. If the string is power-limited the HRL is the better fit; if it is life-limited the XPL is.

How many do I need for a 48 volt string?

Four in series gives a nominal 48 volts. What decides the count beyond that is the runtime, not the voltage: work out the watts per cell your load needs at your required ride-through, then read across the 15 minute or 5 minute column. Send the load and the minutes and a specialist does that arithmetic in writing before you order.

Will my existing charger suit it?

Check two numbers. Float has to sit in the 13.5 to 13.8 VDC per battery band at 25°C, and charge current must stay at or under 18.30 amps. A rectifier fixed above 13.8 volts is the most common reason a long life block never reaches its design life, so tell us the setting before you order rather than after.

Next rating up: CSB XPL2700253 watts per cell at 15 minutes and 59 Ah, in exactly the same case for 4.12 more pounds.
Sizing an XPL string?

Send the cabinet, the load and the ride-through you need. A specialist confirms the 2200 carries it or names the size that does, in writing with no obligation to buy.
