CSB HRL12150W 12V 150W High Rate Discharge AGM Battery for UPS Applications

$149.95
SKU: HRL12150-W
Availability: Request Quote For Availability
Shipping: Free shipping on orders $75 and up
Voltage: 12
Capacity: 37 Ah (20-hour rate, CSB price list); 156 W per cell (15-min to 1.67 VPC at 25C)
Chemistry: AGM VRLA, pure lead construction
Terminal: I2 threaded insert, M6 bolt, 44.9 +/- 9.0 lbf-in
Features: High rate long life, group U1, flame retardant case standard, 4-year CSB term
Group Size: U1
Dimensions: 7.70 x 5.12 x 6.77 in (L x W x H)
Design Life: Up to 10 years standby at 25C; Eurobat 20C greater than 12 years
CSB HRL12150W 12V 150W High Rate Discharge AGM Battery for UPS Applications

CSB HRL12150W 12V 150W High Rate Discharge AGM Battery for UPS Applications

$149.95
Adding to cart… The item has been added
Description

CSB HRL12150WG Battery - 12V 156W Per Cell High Rate Long Life AGM

The HRL12150WG delivers 156 watts per cell at the 15 minute rate to 1.67 volts per cell at 25°C, which is 936 watts across the block, and it is the only part in CSB's High Rate Long Life range at this size rated for a ten year design life. That figure is the reason to specify it. Everything smaller in the HRL band, the 1280W and the 12110WFR included, is rated to eight years and carries a two year warranty; this block steps into the mid-to-large band where CSB gives four. The WG in the part number is a variant designation rather than a different battery: CSB publishes one discharge table for the HRL12150W and the HRL12150WG, so the electrical figures on this page are the same ones the plain W carries. What separates this size in practice is the terminal, an I2 threaded insert taking an M6 bolt where the smaller HRL blocks use a push-on tab. The block runs 26.34 lbs in a group U1 case 7.70 by 5.12 inches standing 6.77 inches tall, with 7.30 milliohms of internal resistance and 1,116 amps of short circuit current.

Warranty

Warranty. CSB gives 4 years on the HRL mid-to-large band, which is where this part sits. Design life is a separate figure: up to 10 years in standby service at 25°C (77°F), and greater than 12 years on the Eurobat 20°C basis. Country of origin is Taiwan. Terms are confirmed in writing with your quote.

Where the HRL Band Changes Gear

156 watts per cell at 15 minutes
To 1.67 volts per cell at 25°C, or 936 watts across the block, with 271 watts per cell at the 5 minute rate.
10 year design life
At 25°C, against eight years for every smaller part in the HRL range, and greater than 12 years on the Eurobat basis.
1,116 amps short circuit current
At 7.30 milliohms, the lowest resistance in the HRL band and the pair a protective device rating gets set against.
  • 37 Ah at the 20 hour rate - per the CSB price list, in BCI group U1; the per-part datasheet rates this series in watts per cell rather than amp hours.
  • 82.2 amps at the 15 minute rate - to 1.67 volts per cell, rising to 152 amps over 5 minutes and 107 amps over 10.
  • 15.0 amps maximum charge current - the recharge ceiling per block, and what the rectifier gets sized on across a string.
  • 225 amps maximum discharge current - a lower ceiling than the smaller HRL1280W at 300 amps, because that limit follows the terminal and plate group rather than capacity.
  • No 30 second rating is published - CSB prints a dash in that row across the HRL range, so a worksheet built on a 30 second column has to fall back on the 5 minute figure.

Technical Specifications

CSB HRL12150WG Specifications
Part NumberHRL12150WG (also written HRL 12150WG, HRL12150WGFR and hrl12150wg; CSB's price list orders it as HRL 12150WGFR, where FR denotes the flame retardant case, marked standard on this part)
Relationship To The HRL12150WSame discharge table. CSB publishes one set of electrical figures covering both, so the G is a variant designation and not a different battery
SeriesHRL, High Rate Long Life, 12 volt top terminal
Battery TypeAGM, valve regulated lead acid (VRLA), pure lead construction
Nominal Voltage12V
Watts Per Cell, 15 Minutes156 W to 1.67 VPC at 25°C (936 W per block)
Watts Per Cell, 5 Minutes271 W to 1.67 VPC at 25°C (1,626 W per block)
Watts Per Cell, 30 SecondsNot published by CSB for the HRL range
Capacity37 Ah at the 20 hour rate (CSB price list)
Discharge Current, 15 Minutes82.2 A to 1.67 VPC at 25°C
Discharge Current, 5 Minutes152 A to 1.67 VPC at 25°C
Maximum Charge Current15.0 A
Maximum Discharge Current225 A
Short Circuit Current1,116 A
Internal ResistanceApproximately 7.30 milliohms
Terminal TypeI2 threaded lead alloy insert to accept an M6 bolt
Terminal Torque44.9 ± 9.0 lbf-in (5.10 ± 1.0 N·m)
Length7.70 ± 0.08 inches (195.6 ± 2.0 mm)
Width5.12 ± 0.06 inches (130.0 ± 1.5 mm)
Height6.77 ± 0.08 inches (172.0 ± 2.0 mm)
Weight26.34 lbs (11.95 kg)
BCI Group SizeU1 (CSB price list)
Float Charging Voltage13.5 to 13.8 VDC per battery at 25°C (77°F)
Equalization Charging Voltage14.4 to 15.0 VDC per battery at 25°C (77°F)
Operating TemperatureNominal 25°C (77°F); discharge -15°C to 50°C (5°F to 122°F); charge and storage -15°C to 40°C (5°F to 104°F)
Container MaterialABS (UL 94-HB) on the base part; the flame retardant 94-V0 case is what the FR build supplies, and the CSB price list marks it standard on this part number
StandardsIEC 61056-1/2:2012; UL1973 Listed (MH66728); UL1989 Recognized (MH14533); TUV NORD to ISO 9001:2015
Design LifeUp to 10 years in standby service at 25°C; greater than 12 years on the Eurobat 20°C basis, described by CSB as Very Long Life
Warranty4 years (CSB, HRL mid-to-large band)
Country of OriginTaiwan
Technical Documentation
CSB HRL12150W datasheet, 2026 (PDF)

Where This Battery Is Used

  • Mid-size UPS cabinets on a ten year replacement cycle - where the design life figure decides the total cost rather than the purchase price.
  • Telecom and network cabinets with bolted connections - installations where a threaded insert is specified and a Faston tab will not pass inspection.
  • Switchgear and controls standby - float duty at full charge for years, judged on what the block delivers in the first fifteen minutes.

Ordering and Freight

At 26.34 lbs single blocks move by parcel carrier and string quantities palletize to LTL. Freight sets ship pre-paid to a commercial address, and a residential or limited-access delivery adds $100, the liftgate and access charge the carrier passes through. Send the block count, the string voltage and your delivery ZIP, and a specialist returns volume pricing, lead time and freight in writing in 24 to 48 hours.

Frequently Asked Questions

What is the difference between the HRL12150W and the HRL12150WG?

Electrically, nothing that CSB publishes. One discharge table covers both part numbers, so the watts per cell, the currents, the resistance and the short circuit figure are identical. The G is a variant designation. We list them as two products because they are ordered as two part numbers and a specification often names one or the other, so quoting the wrong suffix causes a rejected submittal. Send the part number printed on the block coming out and a specialist matches it exactly.

Why does this carry four years when the HRL1280W carries two?

CSB splits the HRL range into two warranty bands and this is where the line falls. The small band runs 634WF2, 1210WF2FR, 1225WF2FR, 1234WF2FR, 1280W and 12110WFR at two years, made in Vietnam. The mid-to-large band starts here at 12150WGFR and runs through 12540WFR at four years, made in Taiwan. Design life moves with it, eight years below the line and ten above. Size is not what changes; the band is.

Can it go where a group U1 flooded battery sits now?

Dimensionally yes, and the duty is the question worth asking instead. This is a sealed AGM built for high rate discharge and permanent float, so it wants a charger holding 13.5 to 13.8 volts and it is not intended for repeated deep cycling. A flooded U1 in a wheelchair or a mower is doing a different job. Where the U1 came out of a UPS or a switchgear cabinet, this is the right family. Send the application with your quote request and it gets confirmed before anything ships.

Why is the maximum discharge current lower than on the smaller HRL1280W?

Because that ceiling is set by the terminal and the plate group rather than by how much energy the block holds. CSB rates the HRL1280W at 300 amps and this larger part at 225. The figures that do scale with size are the sustained ones: 156 watts per cell against 80.83, 1,116 amps of short circuit current against 723, and 7.30 milliohms against 9.00. Size a string on the watts column and check the discharge ceiling separately against your worst case inrush.

The same battery, plain W suffix: CSB HRL12150WIdentical discharge table and the same 4-year CSB term, listed under the part number without the G.
Specifying a ten year standby string?

Send the transfer window you have to cover, the cabinet dimensions and the part number running today. A specialist works the string against the 15 minute column and quotes it with lead time in writing.

Call 1-877-775-4381  ·  battery specialists, not a call center
