NorthStar NSB190FT RED Battery - 12V 190Ah Pure Lead Front Terminal AGM
NorthStar NSB190FT RED Battery - 12V 190Ah Pure Lead Front Terminal AGM
NorthStar NSB190FT RED Battery - 12V 190Ah Pure Lead Front Terminal
Warranty
Why Pure Lead Holds Up on Float
- Holds a charge in storage for up to 24 months - you can keep spares on a shelf without a maintenance charger babysitting them.
- Rated for extra service life at a sustained 40°C (104°F) - built for cabinets that run hot rather than derating steeply in them.
- Made in the USA in plants run to strict lead-containment standards.
Technical Specifications
| NorthStar NSB190FT RED Specifications | |
|---|---|
| Part Number | NSB190FT-RED (also written NSB190FT RED, and searched as NSB190FT, northstar nsb190ft, nsb 190ft) |
| Battery Type | Pure lead AGM, valve regulated (VRLA) |
| Nominal Voltage | 12V |
| Nominal Capacity | 190Ah at the 10-hour rate |
| Terminal Type | Front terminal, female M8 x 1.25 |
| Length | 22 inches |
| Width | 4.9 inches |
| Height | 12.6 inches |
| Weight | 123 lbs |
| Operating Temperature | -40°C to +65°C (-40°F to +149°F) |
| Shelf Life | Up to 24 months |
| Case | Flame retardant, UL 94 V-0, LOI at least 28% |
| Transport | Classified non-hazardous for ground, sea and air |
| Design Life | 15-year EUROBAT design life (NorthStar) |
| Warranty | 3 years full replacement at or below 77°F average ambient, 18 months above 77°F up to 95°F (NorthStar), plus 1-year free replacement through High-Tech Battery Solutions |
Where This Battery Is Used
- Central offices and cell sites - the -48V plant string that has to carry the site until the generator picks up.
- Cable and broadband plant - node and hub cabinets where a truck roll costs more than the battery.
- Emergency lighting and egress systems - code-driven backup that an inspector will actually test.
- Rail signalling and transit - wayside cabinets that swing through a full temperature year.
- Oil, gas and remote telemetry - unmanned sites where the next service visit is scheduled, not immediate.
Ordering and Freight
Frequently Asked Questions
Which warranty term applies to my site, 3 years or 18 months?
It turns on the average day ambient where the batteries actually sit, not the room's design temperature or the thermostat setpoint. Take a reading across a full duty cycle in the warmest season. At or below 77°F you are in the 3-year tier. Above that and up to 95°F you are in the 18-month tier. Send us the figure and we will put the applicable term on the quote in writing so there is no argument later.
How is a 15-year design life different from the warranty?
Design life is NorthStar's engineering estimate of how long the cell can serve under ideal float conditions. The warranty is the period they will replace a failed unit. The gap between the two is normal across the industry and it is not a catch, but any seller quoting you a design life as though it were a warranty is either careless or hoping you will not check.
What happens if a cabinet runs hotter than 95°F?
Coverage is void once cell temperature passes 95°F for more than 30 days in a 365-day period, so a cabinet with a failed fan can cost you the warranty before it costs you the battery. If you know a site runs hot, say so up front and we will talk about whether a high-temperature line is the better buy.
How do I confirm the NSB190FT RED is the right battery before ordering?
Send a photo of the label on the unit you are replacing plus the tray dimensions. Voltage, terminal type and footprint are the three that have to match, and the M8 front terminal is the detail most often missed. We would rather talk you out of the wrong battery than process the return.
Why is there a four-unit minimum order?
Each battery weighs 123 lbs and moves by freight, so a single-unit shipment costs nearly what four cost. The minimum keeps the per-unit freight sane and matches how these strings get built anyway.
Send the quantity, your delivery ZIP, your requested-by date and the site's average ambient. A specialist confirms availability, the applicable warranty term, volume pricing and freight in writing, with no obligation to buy.
